User Manual for Oscar GNSS Receiver v2.4

1.3.2 Battery and charger

Oscar equips smart lithium batteries which can detect electricity and display

the power level intelligently. The Oscar GNSS receiver can also be powered by

external power source via serial data port. The built-in large capacity battery is

detachable, two batteries support up to 16 hours of field work in 4G/3G/2G

mode and rover radio mode.

The BN20 battery is shown as below. Press the button on the top, it shows the

power level left to be consumed.

Figure 1.8 BN20 Battery

The CN20 Charger is able to charge two BN20 batteries at the same time

which is shown in the figures below.

Figure 1.9 CN20 Charger
