2.1.3 Fix Oscar on a tripod or ranging pole

Oscar GNSS receiver has a standard 5/8” x 11 UNC-2B connector and it can

be fixed on a tripod or a ranging pole to be a base or rover according to

customer requirement.

Figure 2.4 Oscar as a base without radio antenna

Table 2.1 Devices to set Oscar as a base without radio antenna

Device Name

Quantity

Items in the figure

Oscar GNSS receiver

1, details refer to section 1.3.1

Height measure accessory

2, details refer to section 1.3.4

GNSS antenna connector

3, details refer to section 1.3.4

Tribrach

Tripod
