4.1Base station operation

Figure 4.1 Oscar as a base - network mode

Table 4.1 Devices of Oscar as a base network mode

NO.

Device Name

Oscar GNSS receiver

Height measure accessory

GNSS antenna connector

Tribrach

Tripod

Figure 4.2 Oscar as a base - internal radio
