User Manual for Oscar GNSS Receiver v2.4

The tape measure below is to help measure height.

Figure 1.26 Tape measure

The 410-470MHz radio whip antenna is to be installed on the TNC port to

transmit or receive signal for the internal radio.

Figure 1.27 410-470MHz radio whip antenna

Figure 1.28 Mini USB cable

Mini USB cable functions:

1. Connect Oscar to the USB port of computer for data downloading;

2. Connect the mini USB port of TC20 to charge TC20 controller.
