2.2Oscar configuration
You can configure Oscar GNSS receiver via buttons, TC20 controller or other
android devices.
2.2.1Configure via buttons
2.2.1.1Button configuration
The detailed definition of buttons on Oscar GNSS receiver refers to Figure 1.4,
Table 1.1, and related context. The OLED screen is display for Ultimate and
Advanced versions, and no display for Basic version. Therefore the button
configurations are different which are listed below.
Table 2.3 Button configuration for Oscar Ultimate and Advanced
Action
Button operation
Description
Turn on the receiver
Press the power button for
2s
All four LEDs light up and remain for
3s, then all go off and battery LED is
steady green if battery level is >30%.
Turn off the receiver
Press the power button for
3s
All four LEDs light off.
Wake up
Tap the power button or
FN button to wake up the
OLED screen when the
OLED screen is off.
Screen off to on.
Select
Press FN button
Confirm
Press the power button
Confirm, cancel, or return.
Reset GNSS module
Press and hold the FN
button, continuously tap
the power button 5 times
All LEDs light up for 5 seconds.
