User Manual for Oscar GNSS Receiver v2.4

1.3 Devices in the package

The devices in the package may vary according to the customer requirement.

Here describes the major parts in the package.

1.3.1 Oscar GNSS receiver

The Oscar GNSS receiver has three versions which are shown as below.

Figure 1.1 Oscar GNSS receiver - Ultimate

Figure 1.2 Oscar GNSS receiver - Advanced

Figure 1.3 Oscar GNSS receiver - Basic
