User Manual for Oscar GNSS Receiver v2.4
88
Storage
built-in 16GB/8GB
Data format
CMR, CMR+ (GPS only), RTCM 2.X/3.X
Data output
RINEX, NMEA-0183, Tersus Binary
Software Support
Tersus Nuwa, MicroSurvey FieldGenius
Communication
Cellular
4G LTE/TD-SCDMA/WCDMA/GPRS/GSM
Cellular bands
FDD LTE B1/B2/B3/B4/B5/B7/B8/B20
WCDMA B1/B2/B5/B8
GSM/GPRS 1900/1800/900/850MHz
Network protocols
Ntrip Client, Ntrip Server, Tersus Caster Service (TCS)
Wi-Fi
802.11b/g
Bluetooth
4.1
Internal radio
RF transmit power
0.5W/1W/2W
Frequency
410MHz ~ 470MHz
Operating mode
Half-duplex
Channel spacing
12.5KHz / 25KHz
Modulation type
GMSK, 4FSK
Air baud rate
4800/9600/19200 bps
Distance (typical)
>5km
Radio protocols
TrimTalk450, TrimMark 3, South,
Transparent, Satel
USB OTG
USB 2.0 x1
Serial ports
RS232 x1
COM baud rate
Up to 921600bps
Electrical
Input voltage
+9 ~ 28V DC
Power consumption
Network or radio receive mode
≈ 5W
Radio transmit mode (0.5W)
≈ 8W
Radio transmit mode (1W)
≈ 9W
Radio transmit mode (2W)
≈ 11W
Lithium battery
7.4V 6400mAh x2
Physical
Display
1.54'' OLED for Ultimate & Advanced versions
Dimension
157*157*103 mm
Weight
≈ 1.2kg (without battery), ≈ 1.4kg (with a battery)
Screw hole for assembly
5/8”x11UNC-2B
Vibration
MIL-STD-810G,FIG.514.6C-1
Environmental
Operating temperature
-40

C to +70

C
Storage temperature
-55

C to +85

C
