TESTO 350 - Page 36

36
The individual components (i.e. control unit with analyzer box or
analyzer box with analyzer box) can be connected to a bus system
using the testo data bus cable.
Before starting up a bus system, the bus address and bus
rate of the connected components must be changed.
For this, before the components are connected to a bus system,
each component must be configured separately either with the
control unit or the notebook/PC.
Calling up the function:
[
] → Device settings → [OK] → Data bus → [OK].
Bus address
The bus address of each component connected to the testo data
bus must be unambiguous. The bus address of the connected
component can be changed, if necessary.
1. Bus Address → [Change]
2. Setting a new bus address: [ ], [ ], [◄], [►].
3. Confirm the entry: [OK].
Bus rate
The relevant data rate must be selected depending on the number
of connected components in a system.
• Control unit with one measuring box: 500 kbit/s
• All other systems: 50 kbit/s
> Select bus rate 500 kbit/s or 50 kbit/s: [
], [ ], → [Change]
→ [
] or [ESC].
