Texas Instruments C2000 Workshop Guide And Lab Manual

ePWM
7 - 18 C2000 Microcontroller Workshop - Control Peripherals
ePWM Action Qualifier S/W Force
Register
EPwmxRegs.AQSFRC
ACTSFARLDCSF OTSFB ACTSFB OTSFA
1 - 015 - 8
reserved
24 - 357 - 6
AQSFRC Shadow Reload Options
00 = load on event CTR = 0
01 = load on event CTR = PRD
10 = load on event CTR = 0 or CTR = PRD
11 = load immediately (from active reg.)
One-Time S/W Force on Output B / A
0 = no action
1 = single s/w force event
Action on One-Time S/W Force B / A
00 = do nothing (action disabled)
01 = clear (low)
10 = set (high)
11 = toggle (low → high; high → low)
ePWM Action Qualifier Continuous S/W
Force Register
EPwmxRegs.AQCSFRC
CSFACSFB
1 - 015 - 4
reserved
3 - 2
Continuous S/W Force on Output B / A
00 = forcing disabled
01 = force continuous low on output
10 = force continuous high on output
11 = forcing disabled
