Interrupts
C2000 Microcontroller Workshop - Reset and Interrupts 4 - 11
Interrupt Flag Register (IFR)
Interrupt Flag Register (IFR)
RTOSINT DLOGINT INT14 INT13
INT12 INT11
INT10 INT9
8
9
10
11
121314
15
INT8 INT7 INT6 INT5 INT4 INT3 INT2 INT1
0
1
2
3
456
7
Pending : IFR
Bit
= 1
Absent : IFR
Bit
= 0
 Compiler generates atomic instructions (non-interruptible) for setting/clearing IFR
 If interrupt occurs when writing IFR, interrupt has priority
 IFR(bit) cleared when interrupt is acknowledged by CPU
 Register cleared on reset
/*** Manual setting/clearing IFR ***/
extern cregister volatile unsigned int IFR;
IFR |= 0x0008; //set INT4 in IFR
IFR &= 0xFFF7; //clear INT4 in IFR
Interrupt Enable Register (IER)
Interrupt Enable Register (IER)
RTOSINT DLOGINT INT14
INT13
INT12 INT11 INT10
INT9
8
9
10
11
121314
15
INT8 INT7 INT6 INT5 INT4 INT3 INT2 INT1
0
1
2
3
456
7
Enable: Set IER
Bit
= 1
Disable: Clear IER
Bit
= 0
 Compiler generates atomic instructions (non-interruptible)
for setting/clearing IER
 Register cleared on reset
/*** Interrupt Enable Register ***/
extern cregister volatile unsigned int IER;
IER |= 0x0008; //enable INT4 in IER
IER &= 0xFFF7; //disable INT4 in IER
