External Interrupts
5 - 16 C2000 Microcontroller Workshop - System Initialization
External Interrupts
External Interrupts
 3 external interrupt signals: XINT1, XINT2
and XINT3
 XINT1, XINT2 and XINT3 can be mapped to
any of GPIO0-31
 XINT1, XINT2 and XINT3 also each have a
free-running 16-bit counter that measures
the elapsed time between interrupts

The counter resets to zero each time the
interrupt occurs
External Interrupt Registers
 Pin Selection Register chooses which pin the signal comes out on
 Only one pin can be assigned to each interrupt signal

Configuration Register controls the enable/disable and polarity

Counter Register holds the interrupt counter
Interrupt Pin Selection Register Configuration Register Counter Register
(GpioIntRegs.register) (XIntruptRegs.register) (XIntruptRegs.register)
XINT1 GPIOXINT1SEL XINT1CR XINT1CTR
XINT2 GPIOXINT2SEL XINT2CR XINT2CTR
XINT3 GPIOXINT3SEL XINT3CR XINT3CTR
