Texas Instruments C2000

F28335 controlCARD
C2000 Microcontroller Workshop - Appendix A - Experimenter's Kit A - 9
SW2
The boot options used in this workshop are shown below:
Position 1
(GPIO-84)
Position 2
(GPIO-85)
Position 3
(GPIO-86)
Position 4
(GPIO-87)
Boot Mode
0 0 1 0 SARAM
1 1 1 1 FLASH
For a complete list of boot mode options see the F2833x Boot Mode
Selection table in the Docking Station section in this appendix.
