Operation
Instrument Controls Menu
Thermo Electron Corporation Model 48i Instruction Manual 3-43
Communication Protocol The Communication Protocol screen, is used to change the instrument
communication protocol for serial communications.
• In the Main Menu, choose Instrument Controls > Communication
Settings > Communication Protocol.
• Use and for a list of choices.
•Press to save the new protocol.
• Press to return to the Communication Settings menu or
to return to the Run screen.
Streaming Data Configuration The Streaming Data Configuration is used to allow for configuration of the
streaming data output.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
INSTRUMENT ID:
CURRENTLY: 48
SET TO: 50 ?
©ª
CHANGE VALUE
SAVE VALUE
RANGE AVG DIAGS ALARM
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
COMMUNICATION PROTOCOL:
CURRENTLY: CLINK
SET TO: STREAMING ?
©ª
CHANGE VALUE
SAVE VALUE
RANGE AVG DIAGS ALARM
