Operation
Instrument Controls Menu
Thermo Electron Corporation Model 48i Instruction Manual 3-61
Analog Output Configuration The Analog Output Configuration menu displays a list of the analog output
channels available for configuration. Configuration choices include
selecting range, setting minimum/maximum values, and choosing signal to
output.
Note The current outputs are displayed only if the I/O expansion board
option is installed.
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Analog Output Config.
• Use and to move the cursor up and down.
• Press to select a choice.
• Press to return to the I/O Configuration menu or to
return to the Run screen.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
SELECT OUTPUT CHANNEL:
>ALL VOLTAGE CHANNELS
ALL CURRENT CHANNELS
VOLTAGE CHANNEL 1
VOLTAGE CHANNEL 2
VOLTAGE CHANNEL 3
VOLTAGE CHANNEL 4
VOLTAGE CHANNEL 5
ª
RANGE AVG DIAGS ALARM
VOLTAGE CHANNEL 6
CURRENT CHANNEL 1
CURRENT CHANNEL 2
CURRENT CHANNEL 3
CURRENT CHANNEL 4
CURRENT CHANNEL 5
CURRENT CHANNEL 6
