Operation
Instrument Controls Menu
Thermo Electron Corporation Model 48i Instruction Manual 3-63
Minimum and Maximum Value The MinimumValue screen is used to edit the zero (0) to full-scale (100)
value in percentages for the selected analog output channel. See Table 3-6
for a list of choices. The minimum and maximum output value screens
function the same way. The example below shows the set minimum value
screen.
• In the Main Menu, choose Instrument Controls > IO Configuration >
Analog Output Config > Select Channel > Set Minimum or Maximum
Value.
• Use and to increment or decrement the numeric value.
• Press to validate and save the new minimum value.
• Press to return to the Analog Output Configuration menu or
to return to the Run screen.
Table 3-6. Analog Output Zero to Full-Scale Table
Output Zero % Value Full-Scale 100% Value
CO Zero (0) Range Setting
LO CO Zero (0) Range Setting
HI CO Zero (0) Range Setting
Range Status (NOx) Recommend not to change the setting for this output
S/R Ratio 0.0 1.2
LO S/R Ratio 0.0 1.2
HI S/R Ratio 0.0 1.2
Internal Temp User-set alarm min value User-set alarm max value
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
MINIMUM OUTPUT PERCENT:
SELECTED OUTPUT: V ALL
CURRENTLY: N/A %
SET TO: 0000.5 % ?
©ª
CHANGE VALUE
SAVE
RANGE AVG DIAGS ALARM
To Next Page
