Thermo 48i - Page 87

Operation
Instrument Controls Menu
Thermo Electron Corporation Model 48i Instruction Manual 3-65
Analog Input Configuration The Analog Input Configuration menu displays a list of the analog input
channels available for configuration. Configuration includes entering
descriptor, units, decimal places, and choice of table points.
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Analog Input Config.
• Use and to move the cursor up and down.
• Press to select a choice.
• Press to return to the I/O Configuration menu or to
return to the Run screen.
Note The current outputs are only displayed if the I/O expansion board
option is installed.

Table 3-7. Signal Types
Concentrations Other Measurements Analog Inputs
None None None
CO (single range mode only) Sample/Reference Analog Input 1
LO CO (dual/auto range only) LO Sample/Reference Analog Input 2
HI CO (dual/auto range only) HI Sample/Reference Analog Input 3
Range Status Internal Temperature Analog Input 4
Bench Temperature Analog Input 5
Aux Temperature Analog Input 6
Bench Pressure Analog Input 7
Sample Flow Analog Input 8
Intensity
Motor Speed
