Operation
Instrument Controls Menu
Thermo Electron Corporation Model 48i Instruction Manual 3-67
• Press to save the new descriptor.
• Press to return to the Analog Input Config menu or to
return to the Run screen.
Units The Units screen allows the user to enter the units for the selected analog
input channel. The units are displayed on the diagnostic screen and in
datalogging and streaming data. The units may be from 1 to 3 characters in
length, and defaults to V (volts).
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Analog Input Config > Select Channel > Units.
• Press to save the new value.
• Press to return to the Analog Input Config menu or to
return to the Run screen.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
ANALOG INPUT DESCRIPTOR:
ASSSSSSSSSSSS
ABCDEFGHIJKLMN BKSP
OPQRSTUVWXYZ PAGE
0123456789 ./- SAVE
RANGE AVG DIAGS ALARM
