17. CHECK AND ADJUSTMENT
17-14
The error quantity between H and V
angle calculated from manual
collimating and auto tracking will be
displayed.
2)
ADJ AXIS (M)
V: 0' 10"
H: 0' 20"
SET OK [YES] [NO]
SET!!
After confirming the display value,
press [F3] (YES) key.
The compensation value will be set and
memorized to AP-L1A.
[F3]
11
Confirm if the center of telescope reticle
and the center of prism is coincided. If
not, repeat from the procedure .
TRK 2/3
F1 : ADJ AXIS(M)
F2 : ADJ AXIS(A)
F3 : TRK SPEED
1) The display shows "NOT TRACKING" when tracking mode is not set, or the target prism is not
found. Repeat the procedure .
2) The display shows "OFF SET OVER" when the calculated compensation value is exceeded than
limited value of
5'. Press [F4] (CLR) key to carry out from the step . Even "OFF SET OVER"
displays, the instrument is required repair.
In case to stop adjusting procedure on half way, press the [ESC] key.
