15.1 PARAMETERS
15.1.1 TRK : Setting for Tracking Functions
1) SEARCH
 PATTERN : Setting search pattern (Refer to Chapter 7.3 "Setting Tracking Parameter" )
Set the searching method in search mode.
Selecting items Contents
HIGH Search in high speed
NORMAL Search in normal speed
 Setting value at shipping time from factory is NORMAL
 AREA : Setting search range (Refer to Chapter 7.3 "Setting Tracking Parameter")
When the prism is lost during tracking mode, the seeking range can be set which is
rotating the range for telescope and body to search for the lost prism.
Set search pattern first, then set search range to the each search pattern.
Set range
0  H angle  180
0  V angle  180 From the point lost the prism
 Setting value at shipping time from factory is
Normal H :10 V :2. High H :10 V :10.
2) WAIT TIME: Setting the waiting time
The time the prism is lost before AP-L1A starts the SEARCH during Tracking mode.
If the mode is set in “HOLD", mode will not change to SEARCH mode.
Setting time
0:00 (0minute 0second)  TIME  60:00 (60minutes 0second)
 Setting value at shipping time from factory is 5 seconds
3) SCAN WIDTH : Setting scan width(Refer to Chapter 7.3 "Setting Tracking Parameter".)
Set a laser scanning range during tracking mode
Selecting items Setting scanning range
NARROW (20'20' ) 20'20'
MIDDLE (40'40' ) 40'40'
WIDE (60'60' ) 60'60'
 Setting value at shipping time from factory is MIDDLE.
4) ADJ.AXIS: Setting compensation of Tracking optical axis
This is the adjusting mode for the error between sighting axis and tracking target. There
is two adjusting methods. One for auto mode one for manual (Refer to Chapter 17.5
"Inspection & Adjusting of Optic axis for Auto-Tracking").
Setting range
-5'00" H angle  +5'00"
-5'00" V angle  +5'00"
