17. CHECK AND ADJUSTMENT
17-13
2) Manual Adjustment Procedure
Operating procedure Operating key Display
 Press the [MENU] key from normal
measurement mode.
[MENU]
MENU 1/1
F1 : PARAMETERS
F2 : PROGRAMS
F3 : REMOTE
 Select [F1:PARAMETERS]. [F1]
PARAMETERS 1/1
F1 : TRK
F2 : MEAS
F3 : COM
 Select [F1:TRK] .
[F1]
TRK 1/3
F1 : SEARCH
F2 : WAIT TIME
F3 : SCAN WIDTH
 Press the [F4] key, TRK menu 2/3 will
be shown.
[F4]
TRK 2/3
F1 : ADJ AXIS(M)
F2 : ADJ AXIS(A)
F3 : TRK SPEED
 Select [F1:ADJ AXIS(M)].
[F1]
ADJ AXIS (M)
PRISM
COLLIMATE
SET OK

[YES] – – –
 Adjust H/V jog shuttle until collimating
proper prism center.
 Press the [F3] (YES) key.
[F3]
ADJ AXIS (M)
AUTO
TRACKING
SET OK

[YES] – – –
 Press [A/M] key, tracking the prism.
[A/M]
ADJ AXIS (M)

AUTO
TRACKING
SET OK

[YES] – – –
 Confirm that tracking the prism, and
press the [F3] (YES) key.
1)
The measured data will be checked by
AP-L1A.
[F3]
ADJ AXIS (M) 
AUTO
TRACKING
DATA CHECK
