Topcon AP-L1A - Setting Teach Measurement Parameters

8. APPLICATION MEASUREMENT
8-5
8.2.2 Setting Teach Measurement Parameters
Operating procedure Operating key Display
 Press [MENU] key from the angle or
distance measuring mode.
[MENU]
MENU 1/1
F1 : PARAMETERS
F2 : PROGRAMS
F3 : REMOTE
 Select [F2:PROGRAMS] [F2]
PROGRAMS
F1 : TEACH
F2 : AREA
 Select [F1:TEACH ]
[F1]
TEACH 1/1
F1 : SET POINT
F2 : PARAMETERS
F3 : GO
 Select [F2:PARAMETERS] [F2]
PARAMETERS
F1 : SEARCH
F2 : EDM MODE
F3 : CYCLE TIME
 Select [F1: SEARCH] [F1]
SEARCH ON/OFF
ON
EXIT

ENT
 Press [F2](), [F3](), to select ON /
OFF SEARCH function and press
[F4](ENT) key
[F2]
or
[F3]
[ENT]
PARAMETERS
F1 : SEARCH
F2 : EDM MODE
F3 : CYCLE TIME
 Select [F2:EDM MODE] [F2]
EDM MODE
FINE 1mm
EXIT

ENT
 Press [F2](), [F3]( ), to select mode
and press [F4](ENT) key.
[F2]
or
[F3]
[ENT]
PARAMETERS
F1 : SEARCH
F2 : EDM MODE
F3 : CYCLE TIME
 Select [F3:CYCLE TIME] [F3]
CYCLE TIME
TIME :00 : 00
EXIT    CLR  
 Input cycle time by numeric keys, and
press [ENT] key.
[Example] 2 hours 30 minutes.
The display returns to parameter menu.
2
.
3
0
[ENT]
PARAMETERS
F1 : SEARCH
F2 : EDM MODE
F3 : CYCLE TIME
 Setting cycle time is 1 minute in unit, max.24 hours.
