1. NOMENCLATURE AND FUNCTIONS
1-1
1. NOMENCLATURE AND FUNCTIONS
1.1 Nomenclature
* Laser aperture label and laser warning label are supplied for certain markets.
Telescope rotating
free lever
Tracking indicator
Fuse holder(4A)
Base fixing screw
Base
Leveling screw
Serial Signa
Connector (Port-1)
Horizontal shuttle
Power supply
connector
(DC12V)
Horizontal jog
Power key
A
uto inversion key
REC key
Vertical jog
Vertical shuttle
Instrument center mark
Laser warning
label *
Objective lens
Laser aperture
Laser aperture
label *
Sighting collimator
