15. SPECIAL MODE (MENU KEY OPERATION)
15-4
15.1.2 MEAS : Setting Measurement
1) TILT ON/OFF : Vertical and Horizontal Angle Tilt Correction
Selecting functions for automatic Tilt correction.
Selecting items Description
OFF Auto correction will not be done.
V TILT ON uto correction for Vertical angle only.
V/H TILT ON Auto correction for both H and V angles.
The display of Vertical or Horizontal angle is unstable when AP-L1A is on an unstable
stage or in a windy day. You may decide to turn OFF of auto tilt correction function of
H/V angle in this case. You are required to level precisely. Tilt correction is now
disabled.
Setting at shipping time from factory is V/H TILT ON.
2) DATE & TIME: Setting date and time
Setting clock function of the instrument.
Set items
year/month/date/week/24 hours/60 minutes/60 seconds
[Example] : 1993/09/01/WED/13:10:30
Procedure Operation
Press [MENU] key from the distance or angle measuring mode. [MENU]
Select [F1:PARAMETERS]. [F1]
Select [F2:MEAS]. [F2]
Select [F2:DATE & TIME].
The display shows date and time which is already set.
[F2]
Press [F3:YES] key. [F3]
Input year/month/date, then press [ENT]key. 19930901 [ENT]
Input hours/ minutes/ seconds , then press [ENT]key. 131030 [ENT]
Select a day of the week with [F2:]or [F3:] key.
Pressing [ENT] key, the clock will start.
[F2] or [F3]
[ENT]
3) OCC.POINT: Setting ON/OFF for instrument point coordinate
Setting ON or OFF to memorize the instrument point coordinate which will be or is
preset by the function operating key.
Selecting items Description
OFF The instrument point will not be memorized.
ON The instrument point will be memorized even
after power is off.
Setting value at shipping time from factory is OFF.
4) RST A/M: Setting Auto/Manual mode for resection method (refer to "6.2.2.Resection
Method.")
Set sighting mode in auto or manual for resection method.
Selecting items Description
AUTO Auto sighting Setting value at shipping time from
MANUAL Manual sighting factory is MANUAL
To Next Page
