8. APPLICATION MEASUREMENT
8-4
Select [F2 : PROGRAMS ].
[F2]
PROGRAMS
F1 : TEACH
F2 : AREA
Select [F1:TEACH ].
[F1]
TEACH 1/1
F1 : SET POINT
F2 : PARAMETERS
F3 : GO
Select [F1:SET POINT ]
[F1]
SET TEACH
F1 : WRITE
F2 : DELETE
Select [F1:WRITE] [F1]
TEACH POINT [ 1]
V:
'
"
H:
'
"
EXIT
ENT
Select Measuring point number.
Press [F2](), [F3](), and select
number displayed at the right top, and
press [F4](ENT) key.
[F2]
or
[F3]
[ENT]
TEACH POINT [ 1]
V:
'
"
H:
'
"
EXIT RL MEAS ENT
Select, if desired, option for multiple
observations of same point in both
faces of AP-L1A.
Press [F2](
), [F3]() key, and select
ON/ OFF , and press [F4](ENT) key.
[F2]
[F2]
or
[F3]
[ENT]
R/1 [ 1]
ON
EXIT
ENT
TEACH POINT [ 1]
V: 98
46' 55"
H : 210
55' 25"
EXIT RL MEAS ENT
Press [F3](MEAS) key.
Set the number of observations of the
same point per set. Input number using
numeric key, and press [ENT] key,
[For example, 3 times.]
[F3]
3
[ENT]
DATA COUNT [ 1]
3
EXIT – – – CLR
–
Collimate the control point to be set,
and press [F4](ENT) key..
[ENT]
TEACH POINT [ 1]
V: 65
45' 20"
H : 123
40' 50"
EXIT RL MEAS ENT
SET OK
[ YES ] [ NO ]
PRESS [F3](YES) key.
The control point of number 1 is set.
[F3]
TEACH POINT [ 1]
V: 65
45 ' 20"
H : 123
40 ' 50"
EXIT
ENT
To delete a control point, select [F2:DELETE] in procedure
To Next Page
