1. NOMENCLATURE AND FUNCTIONS
1-7
5 BS F1 Setting direction angle Sets the direction angle from the coordinate of
instrument point and known point.(Backsight Point)
CSET F2 Setting an instrument
point
Sets an instrument coordinate point by input values.
RST F3 Resection Sets instrument coordinate point from two known
points and their measured values.
5
F4 Page The function of soft keys shown in the next page.
6 MOVE F1 Rotation Rotates desired H and V angle.
R.HT F2 Setting target height Allows the user to input the target height.
( Prism Height)
6
F4 Page The function of soft keys shown in the next page.
