6. COORDINATE MEASUREMENT
6-3
[ENT]
 Input Z coordinate. 1)
Example:Z coordinate 2.345m
2
.
3
4 5
[ENT]
OCC. POI
N
T
Z : 2.3450 m
I
N
S. HT : m
EXIT

CLR


0.0000
 Input instrument height. 2
Example: INS.HT 1.3m
1
. 3
[ENT]
OCC. POINT
Z : 2.3450 m
INS. HT : 1.3000 m
EXIT

CLR

SET OK
 
YES
 
NO

 Press [F3](YES)key.
At the end of setting, the mode returns
to the previous setting.
[F3]
V: 90

10
'
20
"
HR : 120

30
'
40
"
BS CSET RST 5

1) When Z coordinate is not input, press [ENT] key only.
2) When instrument height is not input, press [ENT] key only.
Input range:
Coordinate of the instrument
130,000.0000m  N  +130,000.0000m (130km)
  E  
  Z  
Instrument height
10.0000m  INS.HT  +10.0000m
