7. APPLICATION FUNCTIONS
7-5
 Select a setting area Number.
Press [F2](
) or [F3](), and select
the number of right upper corner in the
screen display and press [F4](ENT)
key.
[F2]
or
[F3]
[ENT]
AREA SET
N
: ***.*** m
E : ***.*** m
EXIT

CLR


A [ 2]
 Input coordinate value of point A, and
press [ENT] key.
N Coord.
[ENT]
E Coord.
[ENT]
Z Coord.
AREA SET
Z : 3.4567 m
EXIT

CLR


A [ 2]
The displays changes to input point B.
[ENT]
AREA SET
N
: ***.*** m
E : ***.*** m
EXIT

CLR


B [ 2]
 Input coordinate value of point B, and
press [ENT] key.
N Coord.
[ENT]
E Coord.
[ENT]
Z Coord.
[ENT]
AREA SET
Z : 4.5678 m
EXIT

CLR


SET O
K

[YES] [NO]
B [ 2]
 Press [F3](YES) key.
The area range to be set is diagonal
area range between Points A and B
(area No.2). To set another area,
repeat from the step of .
[F3]
AREA SET
N
: 1234.5678 m
E : 6543.4321 m
EXIT


ENT
A [ 2]
 Press [F1](EXIT) key.
The menu returns to AREA SET.
1)
[F1]
AREA SET 1/1
F1 : INPUT NEZ
F2 : MOVED SET
F3 : SETTING AREA
1) Pressing [ESC] key from the AREA SET menu returns you to PROGRAMS menu, and to return
to normal mode, press [MENU] key.
