4. Attach the flexible RF cable from the external antenna to the
antenna connector on the back panel of the receiver.
5. Continue with other setups or operations as needed.
The receiver antenna default is set to Auto, allowing the receiver to
detect automatically the available antenna (whether internal or
external). If you have changed this setting, or the receiver does not
detect the external antenna, use the procedure below to set the
External Antenna detection option.
1. Connect your receiver and computer, then start PC-CDU. See
“Connecting the Receiver and a Computer” on page 2-11 for
this procedure.
2. Click ConfigurationReceiver (Figure A-3).
Figure A-3. ConfigurationReceiver
3. On the General tab, select the External Antenna option and
click Apply (Figure A-4).
Figure A-4. Select External Antenna Option
4. Click FileDisconnect, then FileExit to quit PC-CDU.
