Toro Multi Pro 1750 - Removing the Agitation Nozzles; Removing Boom-Section Valves, Supply Hoses, and Section-Valve Mount; Removing the Agitation Nozzles from the Sprayer Tank

RemovingtheBoom-SectionValves,
SupplyHoses,andSection-Valve
Mount
1.Removethe4ange-headbolts(5/16x3/4inch)that
securethesection-valvebrackettothesection-valve
mount(Figure18).
Note:Retaintheange-headboltsforinstallationin
InstallingtheSectionValveManifold(page24).
Figure18
1.Bracket(section-valve)2.Flange-headbolt(5/16x
3/4inch)
2.Lifttheboom-sectionvalves,supplyhoses,and
section-valvebracketfromthemachine(Figure19).
Note:Younolongerneedthevalves,hoses,and
bracket.
Figure19
6
RemovingtheAgitation
Nozzles
NoPartsRequired
RemovingtheAgitationNozzlesfrom
theSprayerTank
1.Removethe3retainersthatsecuretheagitationnozzles
tothebulkheadttingsattheleftsideofthesprayer
tank(Figure20).
Note:Retaintheretainersforinstallationin13
InstallingtheAgitation-NozzleAssemblyandHoses
(page30).
Figure20
1.Bulkheadtting
3.Retainer
2.Agitationnozzle
2.Removetheagitationnozzlesfromthebulkhead
ttings(Figure20).
