2.Removetheretainerthatsecuresthesectionvalve
manifoldtothebypasstting(Figure115).
Figure115
1.Retainer
3.Manifold-valveassembly
2.Socket(bypasstting)4.Socket(outlettting)
3.Removethesectionvalvemanifoldfromthemachine
(Figure116).
Figure116
1.Bypasstting2.Sectionvalvemanifold
CleaningtheManifoldValve
1.Positionthevalvestemsothatitisintheclosed
position(Figure117).
Figure117
1.Valveopen2.Valveclosed
2.Removethe2end-cap-ttingassembliesfromeachend
ofthemanifoldbody(Figure118andFigure119).
55
