DisconnectingtheOptional

Attachments

NoPartsRequired

DisconnectingtheOptionalEductorKit

1.Removetheangeclampthatsecurestheanged

hose-barbofthesupplyhosetotheinletangeofthe

eductor(Figure9).

Figure9

1.Inletange(eductor)

3.Flangeclamp

2.Gasket

4.Flanged-hose-barb

(supplyhose)

2.Removetheangedhosebarbandgasketfromthe

eductor(Figure9).

Note:Retaintheangeclampandgasketfor

installationin18InstallingtheSupplyHoseforthe

OptionalEductorKit(page47).Younolongerneed

thesupplyhoseandyouwillremoveitwiththe

agitation,rate,andmastersprayvalvesin7Removing

theAgitation,Rate,andMaster-SprayValves(page14).

3.Removetheretainerthatsecuresthe90°barbedtting

ofthesprayersupplyhosetotheT-ttinglocated

forwardofthepressure-reliefvalve(Figure11).

Note:RetaintheretainersforinstallationinInstalling

theSprayerSupplyHose—Machinewithoutthe

OptionalEductorKit(page34).

Figure10

Figure11

1.Retainer

5.Sprayersupplyhose

2.90°barbedtting(sprayer

supplyhose)

6.Pressure-reliefvalve

3.Frontofthemachine

7.3-wayvalve

4.T-tting

4.Removethe90°barbedttingfromtheT-tting

(Figure11).
