Toro Multi Pro 1750 Installation Instructions

Figure7
1.Mastersprayvalve4.Valveelectricalconnector
(agitationvalve)
2.Ratevalve5.3-contactconnector
(wireharness—AGITATION
VALVE)
3.Agitationvalve6.Valveelectricalconnector
(mastersprayvalve)
5.Removethe3-contactconnectorofthewireharness
fromthevalve(Figure7).
6.Repeatsteps4and5forthe3-contactconnectorsof
thewireharnesslabeledRATEV ALVEandAGITATION
VALVE.
7.Removethe5push-infastenersofthewire
harnessfromthesection-valvebracketandthe
agitation/rate/master-spraybracket.
Figure8
1.Bracket(throttlevalve)
3.Bracket
(agitation/rate/master-spray
valve)
2.Push-infastener
8
