Toro Multi Pro 1750 Installation Instructions

18
InstallingtheSupplyHosefor
theOptionalEductorKit
Partsneededforthisprocedure:
1
Eductorsupplyhose2x88cm(3/4x34-11/16inches)
1
Retainer(small)
Procedure
1.Alignthestraightbarbedttingoftheeductorsupply
hose2x88cm(3/4x34-11/16inches)withthe
gasketthatyouremovedinstep2ofDisconnecting
theOptionalEductorKit(page9)withtheangeof
theeductor(Figure101).
Figure101
1.Flange(eductor)
5.Eductorsupplyhose2
x88cm(3/4x34-11/16
inches)
2.Gasket
6.Bottomport
(eductor-shutoffvalve)
3.Flangeclamp
7.90°barbedtting
4.Straightbarbedtting8.Retainer(small)
2.Looselyassemblethebarbedttingtotheeductor
angewiththeangeclampthatyouremovedinstep
1ofDisconnectingtheOptionalEductorKit(page9)
3.Routetheeductorsupplyhosetothebottomofthe
eductor-shutoffvalveasshowninFigure102.
47
