Toro Multi Pro 1750 Installation Instructions

WiringTable—RightSprayValve
Wirecolorcodes—DINwire
harness
Wirecolorcodes—3-pin
adapter
BrownPink
BlueBlack
Yellow/green
White
2.InsertthewireoftheDINwireharnessintothe
butt-spliceconnectorofthe3-pinadapter(Figure34).
Figure34
1.3-pinadapter3.Butt-spliceconnector
2.DINwireharness
4.Exposedwire9.5mm(3/8
inch)
3.Centerthecrimpingtooloverthebutt-spliceconnector
andwiresandcrimptheconnectorsecurely(Figure35).
Figure35
1.3-pinadapter
3.Connector(centerspray)
2.Wireharnessbranch(left
spray)
4.Connector(rightspray)
4.Repeatsteps2and3forthe2remainingwires.
5.Useaheatguntoshrinktheinsulatingsleevesofthe3
butt-spliceconnectors(Figure36).
Figure36
18
