Multi Pro 1750
Page 5 − 21
Electrical System
Operator Advisories
The list below identifies the operator advisories that are
generated by the Toro Electronic Controller (TEC). An
advisory will be displayed on the InfoCenter Display.
Typically, an advisory can be eliminated with a change
in machine controls by the operator.
Advisory
Advisory Description
200 Start Prevented − Pump switch active
201 Start Prevented − Not in neutral
202 Start Prevented − User not in seat
203 Start Prevented − Throttle pedal is not home
204 Start Prevented − Starter engage timeout
205 Parking brake is engaged
206 Pump start prevented − boom active
207 Pump start prevented − engine rpm high
208 Throttle/Speed lock prevented − Pump is not active
209 Throttle lock prevented − parking brake is not engaged
210 Speed lock prevented − Operator not in seat or parking brake is engaged
211 Throttle/Speed lock prevented − Clutch or service brake is engaged
212 Tank low volume alert
213 Rinse pump ON
220 Flow sensor calibration
221 Flow sensor calibration − Fill water in tank and enter volume filled
222 Flow sensor calibration − Turn on the pump
223 Flow sensor calibration − Turn on all the booms
224 Flow sensor calibration − Calibration commenced
225 Flow sensor calibration − Calibration complete
226 Flow sensor calibration − Exiting calibration mode
231 Speed sensor calibration
232 Speed sensor calibration − Fill the fresh water tank, press next
233 Speed sensor calibration − Fill the sprayer half full with water, press next
234 Speed sensor calibration − Enter the calibration distance, press next
235 Speed sensor calibration − Mark and drive the entered distance with booms off
236 Speed sensor calibration − Speed sensor calibration in progress
237 Speed sensor calibration − Speed sensor calibration complete
238 Speed sensor calibration − Turn off the booms
241 Calibrator out of bounds, using default
Electrical
System
