Toro Multi Pro 1750 - Control Cable Replacement

Multi Pro 1750Page 7 − 8Drive Train
Service and Repairs
Control Cable Replacement
1. Bottom console cover
2. Right fender assembly
3. Differential lock lever knob
4. Rear switch panel
5. Flange head screw (4)
6. Shift knob
7. Jam nut
8. Shift boot
9. Foam seal
10. Cable clamp
11. 1
st
−Reverse shift cable
12. 2
nd
−3
rd
shift cable
13. Hair pin (3)
14. Clevis (2)
15. Clevis pin (3)
16. Jam nut (2)
17. Differential lock cable
18. Retaining ring
19. Shift stop bolt (2)
Figure 4
FRONT
RIGHT
11
12
13
13
14
15
15
16
17
19
18
Locktite #290
1
2
7
4
5
8
9
10
6
3
