Multi Pro 1750Chassis Page 8 − 4
Special Tools
Order special tools from your Toro Distributor.
Spanner Wrench
Use spanner wrench to rotate front shock absorber col-
lar which changes the length of the shock spring to affect
front wheel camber. Make sure that vehicle is jacked up
off the ground to allow shock spring to be at full exten-
sion before using spanner wrench.
Toro Part Number: TOR6010
Figure 1
Shock Spring Compressor
Use shock spring compressor to remove spring from
front shock absorber.
Toro Part Number: TOR6015
Figure 2
