Multi Pro 1750
Page 5 − 24
Electrical System
Fault Codes
The list below identifies the fault codes that are gener-
ated by the Toro Electronic Controller (TEC) to identify
an electrical system malfunction (fault) that occurred
during machine operation. Use the InfoCenter Display
for fault retrieval.
NOTE: The following list of fault codes identifies elec-
trical problems that typically will prevent normal ma-
chine operation. The InfoCenter Display will identify
existing faults if they should occur. For input problems,
use the InfoCenter Display to check the different switch
positions before removing or replacing the component.
Fault Code
Fault Description
1 TEC is faulty
2 One or more of the TEC output fuses (7.5 Amp) is faulty
3 Main power relay or circuit wiring is faulty
4 Charging system or circuit wiring is faulty
5 Start relay or circuit wiring is faulty
6 Kill relay circuit is faulty
7 Spray pump clutch or circuit wiring is faulty
8 Spray pump indicator light or circuit wiring is faulty
9 Throttle lock or circuit wiring is faulty
10 Throttle lock indicator light or circuit wiring is faulty
11 Master boom valve actuator or circuit wiring is faulty
12 Rinse pump relay, optional rinse pump or circuit wiring is faulty
13 Brake hold solenoid or circuit wiring is faulty
14 InfoCenter software is not recognized by TEC
15 Brake pressure switch or circuit wiring is faulty
(circuit is closed even though the brake pedal has been released)
16 Service brake or throttle home sensor, or circuit wiring, is faulty
(circuit is open even though the brake or accelerator pedal has been released)
17 Starter timeout (starter has been engaged for more than 30 seconds)
