Fault21:IDModuleFault

InfoCenterDisplay:

_____ FAULT#21 _____

IDModule

FaultDescription

EachcuttingreelmotorhasitsownuniquemoduleID.Thisfaultisreportedwheneither:

•anIDmoduleisnotfunctioningatall,or

•morethan1cuttingreelmotorisclaimingthesamenodeID

CircuitDescription

Eachcuttingreelmotorhasanelectronicsignaturecodesoitcanbeidentied.Thesecodesareallmaintained

withinthelocationIDmodule.IfanIDcodeismissing,orifmorethan1cuttingreelmotorreportshavingthe

samecodetotheTEC-5002,fault21isreported.

ConditionsforSettingtheFault

TheTEC-5002hasrecognizedanerrorintheway1ormoreofthemoduleIDsarefunctioning.

RecommendedServiceActions

Step1:Verifythatthefaultrepeats.

1.ClearthesystemfaultsfromtheInfoCenter.RefertoClearingFaultsfromtheInfoCenter(page21).

2.Operatethemachine.

Pass

Thefaultdidnotrepeat.GotoReturningtheMachinetoService(page22)andfollowthestepslisted.

Note:Ifthefaultdoesnotrepeat,anisolatedeventhasoccurred.

Fail

Thefaultrepeated.GotoStep2.

Step2:TestthelocationIDmodule.

1.GotoPreparingforTroubleshootingand/orT esting(page22)andfollowthestepslisted.

2.Raiseandsupporttheoperator’sseatandthehood.

3.Separatesystemcomponentsfromthe48Vdcbatterypackbyunpluggingthe48Vdcbatterydisconnect.

RefertoConnectingandDisconnectingthe48VdcBatterySystem(page19).
