2. SYSTEM MODE EO13-33002
(Revision Date: Mar. 26, 2009)
2.1 Self-diagnostic Test
2- 8
• Descriptions of the Parameters
Item # Description Specification
FEED (11) Print start position fine adjustment (PC), (KEY) -50.0 mm to +50.0 mm
CUT (12) Cut/strip position fine adjustment (PC), (KEY) -50.0 mm to +50.0 mm
BACK (13) Reverse feed amount fine adjustment (PC), (KEY) -9.9 mm to +9.9 mm
TONE(T) (14) Print tone fine adjustment (Thermal transfer), (PC), (KEY) -10 step to +10 step
TONE(D) (15) Print tone fine adjustment (Thermal direct), (PC), (KEY) -10 step to +10 step
RBN(FW) (16) Ribbon take-up motor driving voltage fine adjustment
(PC), (KEY)
-15 step to +0 step
RBN(BK) (17) Ribbon feed motor driving voltage fine adjustment (PC),
(KEY)
-15 step to +10 step
X ADJ. (18) X coordinate fine adjustment -99.9 mm to +99.9 mm
THRESHOLD<R> (19) Threshold manual fine adjustment for the black mark
sensor
0.0V to 4.0V
THRESHOLD<T> (20) Threshold manual fine adjustment for the feed gap sensor 0.0V to 4.0V
Character code PC-850 PC-851 PC-1252 LATIN9 PC-852
PC-855 PC-1253 Arabic PC-857 PC-1250
PC-1254 PC-8 PC-1251 PC-1257 PC-866
UTF-8
FONT (21)
Character “0” 0: without slash
0: with slash
SPEED (22) Baud rate 2400: 2400 bps 19200: 19200 bps
4800: 4800 bps 38400: 38400 bps
9600: 9600 bps 115200: 115200 bps
DATA LENG. (23) Data length 7: 7 bits
8: 8 bits
STOP BIT (24) Stop bit length selection 1: 1 bit
2: 2 bits
PARITY (25) Parity NON: None
ODD: ODD
EVEN: EVEN
CONTROL (26) Flow control code XON/XOFF: XON/XOFF
READY/BUSY: READY/BUSY (DTR)
XON+READ AUTO:
XON/XOFF+READY/BUSY (DTR)
XON/XOFF AUTO: XON/XOFF
READY/BUSY RTS: RTS
MESSAGE (27) Language selection for LCD message ENGLISH: English
GERMAN: German
FRENCH: French
DUTCH: Dutch
SPANISH: Spanish
JAPANESE: Japanese
ITALIAN: Italian
FORWARD WAIT (28) Auto forward wait ON: Available
OFF: Unavailable
NOTE: The stop position fine adjustment
value is also printed out.
HEAD UP CUT (29) Head up cut in cut issue mode ON: Activated
OFF: Not activated
RIBBON SAVE (30) Ribbon saving function ON(TAG): Activated
(When the head lever is set to
the tag position.)
ON(LBL): Activated
(When the head lever is set to
the label position.)
OFF: Not activated
CODE (31) Control code selection AUTO: Automatic selection
ESC LF NUL: ESC LF NUL mode
{ | }: Mainframe mode
xx xx xx: Optional code
(The values are given in HEX.)
To Next Page
