2. SYSTEM MODE
System mode consists of ten main menus: Self-diagnostic test, Parameter setting, Printer parameter fine
adjustment, Test print, Sensor adjustment, RAM clear, IP address setting, Basic setting, and Factory mode.
Each menu is used for the following purposes:
• To check and print the system status, the Maintenance Counter, and the Print Head Element.
• To set the parameters for the communication with the host computer, and the printer functions such as
the language for LCD message, Feed key function, etc.
• To make fine adjustment related to the media issue.
• To perform a test print for checking print quality.
• To check the status of the sensors and to set the threshold of the media sensor for pre-printed media.
• To perform a Maintenance Counter clear and Parameter clear.
• To set the IP address
• To set the Basic setting
• To perform the factory mode
To enter System mode, turn on the printer while pressing the [FEED] and [PAUSE] keys at the same time.
Hold both keys until “<1>DIAG. Vx.x” message appears on the display.
This is the start of the Self-Diagnostic Test
menu. → Section 2.1
This is the start of the Parameter Setting
menu. → Section 2.2
This is the start of the Printer Parameter Fine
djustment menu. → Section 2.3
This is the start of the Test Print menu.
→ Section 2.4
This is the start of the Sensor Adjustment
menu. → Section 2.5
This is the start of the RAM Clear menu.
→ Section 2.6
This is the start of the IP Address Setting
menu. → Section 2.7
[FEED]
[FEED]
[FEED]
[FEED]
[FEED]
[FEED]
[FEED]
[RESTART]
[RESTART]
[RESTART]
[RESTART]
[RESTART]
[RESTART]
[RESTART]
<2>PARAMETER SET
<3>ADJUST SET
<4>TEST PRINT
<5>SENSOR ADJ.
<6>RAM CLEAR
<7>IP ADDRESS
[PAUSE]
[PAUSE]
[PAUSE]
[PAUSE]
[PAUSE]
[PAUSE]
[PAUSE]
<1>DIAG. Vx.x
