4-92 [CONFIDENTIAL] TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784)
9. Remove the following screws and separate the LCD unit and Brake hinges.
S-THIN HEAD screw  M2.03C 2
Figure 4-51 Removing the LCD unit (4)
M2.0x3C S-THIN HEAD
LCD unit
Brake hinge R
Brake hinge L
M2.0x3C S-THIN HEAD
