9. Set the LCD assembly to the guides of the cover assem
following screws.
bly and secure them with the
10. Turn up the insulators (INSU ANT HLD L and INSU ANT HLD R) and arrange the
NOTE: Set the INSU ANT HLD R under the guide.
 M2.55B FLAT HEAD screw 4
 M2.512B FLAT HEAD screw 2
harnesses to the guides of the cover assembly.
4-94 [CONFIDENTIAL] TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784)
