4-96 [CONFIDENTIAL] TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784)
3. Peel off the wireless LAN antennas, 3G antennas and camera harness from the
NOTE: Do not reuse the removed wireless LAN antennas and 3G antennas. Be sure to
LCD cover.
use new wireless LAN antenna or 3G antenna.
Figure 4-53 Removing the wireless LAN antenna/3G antenna
Please prep uired part e, when r llowing ite
Parts List
ITEM No
Quantity
are req s c in advan eplacing the fo m.
ITEM PART NAME
LCD COVER ASSY 1
CAMERA MODULE 1
LCD COVER ASSY
2.4/5.2GHZ ANTENNA 1
Camera harness
Wireless antenna (black)
Wireless antenna (whi
3G antenna (blue)
3G antenna (red)
te)
Insulator
