TP-Link TL-SG5412F Reference Guide

139
be Standard-IP ACL, and 200-299 must be Extend-IP ACL.
Command Mode
Global Configuration Mode
Example
Create a MAC ACL whose ID is 20:
TP-LINK(config)# acl create 20
acl rule mac-acl
Description
The acl rule mac-acl command is used to add MAC ACL rule. To delete the
corresponding rule, please use no acl rule mac-acl command. MAC ACLs
analyze and process packets based on a series of match conditions, which can
be the source MAC addresses, destination MAC addresses, VLAN ID, and
EtherType carried in the packets.
Syntax
acl rule mac-acl {acl-id} {rule-id} [op {discard | permit }] [[smac source-mac]
{smask source-mac-mask}] [[dmac destination-mac] {dmask
destination-mac-mask}] [vid vlan-id] [type Ethernet-type] [pri user-pri] [tseg
time-segment]
no acl rule mac-acl {acl-id} {rule-id}
Parameter
acl-id —— The desired MAC ACL for configuration.
rule-id —— The rule ID.
op —— The operation for the switch to process packets which match the rules.
There are two options, discard and permit. Discard means discarding packets,
and permit means forwarding packets. By default, the option is permit.
source-mac —— The source MAC address contained in the rule.
source-mac-mask —— The source MAC address mask. It is required if you
typed the source MAC address.
destination-mac —— The destination MAC address contained in the rule.
destination-mac-mask —— The destination MAC address mask. It is required if
you typed the destination MAC address.
vlan-id —— The VLAN ID contained in the rule, ranging from 1 to 4094.
Ethernet-type —— EtherType contained in the rule, in the format of 4-hex

TP-Link TL-SG5412F Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Fan	0
Wi-Fi	No
Diagnostics	VCT
Management platform	SNMP, RMON, WEB/CLI/Telnet
Authentication method	802.1X, Radius
Packet transfer speed	17.99Mpps
Connectivity technology	Wired
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
DHCP features	DHCP client
Security algorithms	SSH, SSL/TLS
Switch type	Managed
Switch layer	L2
Console port	RJ-45
Fiber optic connector	SFP
SFP/SFP+ slots quantity	12
Basic switching RJ-45 Ethernet ports quantity	4
Fiber ethernet cabling technology	100BASE-FX
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Stackable	-
Form factor	1U
Certification	CE, FCC
Product color	Black
Compatible operating systems	Windows 98SE, NT, 2000, XP, Vista, Windows 7\\r MAC OS\\r NetWare\\r UNIX\\r Linux
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	260 mm
Width	440 mm
Height	44 mm
