56
Chapter 12 Binding Table Commands
You can bind the IP address, MAC address, VLAN and the connected Port number of the Host
together, which can be the condition for the ARP Inspection and IP Source Guard to filter the
packets.
binding-table user-bind
Description
The binding-table user-bind command is used to bind the IP address, MAC
address, VLAN ID and the Port number together manually.
You can manually
bind the IP address, MAC address, VLAN ID and the Port number together in
the condition that you have got the related information of the Hosts in the LAN.
Syntax
binding-table user-bind hostname ip-addr mac-addr vlan vid port port-num
{none | arp-detection | ip-source-guard | both}
Parameter
hostname ——The Host Name, which contains 20 characters at most.
ip-addr —— The IP Address of the Host.
mac-a
ddr —— The MAC Address of the Host.
vid ——The
VLAN ID needed to be bound, ranging from 1 to 4094.
port-num —— The number of port connected to the Host.
{non
e | arp-detection | ip-source-guard | both}——The protect type for the entry.
arp-
detection indicates ARP detection; ip-source-guard indicates IP filter; none
indicates appling none; both indicates appling both.
Command Mode
Global Configuration Mode
Example
Bind an ACL entry with the IP is 192.168.0.1, MAC is 00:00:00:00:00:01, VLAN
ID is 2 and the Port number is 5 manually. And then enable the entry for the ARP
detection and IP filter function:
TP-LINK(config)# binding-table user-bind host1 192.168.0.1
00:00:00:00:00:01 vlan 2 port 5 both
