157
255.255.255.0, the time-range for the rule to take effect is “tRange1”, and the
packets match this rule will be forwarded by the switch:
TL-SG5428(config)# access-list create 120
TL-SG5428(config)# access-list standard 120 rule 10 permit sip
192.168.0.100 smask 255.255.255.0 tseg tRange1
access-list extended
Description
The access-list extended command is used to add Extended-IP ACL rule. To
delete the corresponding rule, please use no access-list extended command.
Syntax
access-list extended acl-id rule rule-id { deny | permit } [ sip source-ip
smask source-ip-mask ] [ dip destination-ip dmask destination-ip-mask ] [ tseg
time-segment ] [ dscp dscp ] [ s-port s-port ] [ d-port d-port ] [ tcpflag tcpflag ]
[ protocol protocol ]
no access-list extended acl-id rule rule-id
Parameter
acl-id——The desired Extended-IP ACL for configuration.
rule-id —— The rule ID.
deny —— The operation to discard packets.
permit ——The operation to forward packets. It is the default value.
source-ip —— The source IP address contained in the rule.
source-ip-mask —— The source IP address mask. It is required if you typed
the source IP address.
destination-ip —— The destination IP address contained in the rule.
destination-ip-mask —— The destination IP address mask. It is required if you
typed the destination IP address.
time-segment —— The time-range for the rule to take effect. By default, it is
not limited.
dscp —— Specify the dscp value, ranging from 0 to 63.
s-port —— The source port number.
d-port —— The destination port number.
tcpflag —— Specify the flag value when using TCP protocol.
protocol —— Configure the value of the matching protocol.
