168
Command Mode
Interface Configuration Mode (interface gigabitEthernet / interface range
gigabitEthernet)
Example
Enable the STP function of port 1, and configure the Port Priority as 64, ExtPath
Cost as 100, IntPath Cost as 100, and then enable Edge Port:
TL-SG5428(config)# interface gigabitEthernet 1/0/1
TL-SG5428(config-if)# spanning-tree common-config port-priority 64
ext-cost 100 int-cost 100 portfast enable point-to-point open
spanning-tree mode
Description
The spanning-tree mode command is used to configure the STP mode of the
switch. To return to the default configurations, please use no spanning-tree
mode command.
Syntax
spanning-tree mode { stp | rstp | mstp }
no spanning-tree mode
Parameter
stp ——Spanning Tree Protocol, the default value.
rstp ——Rapid Spanning Tree Protocol
mstp ——Multiple Spanning Tree Protocol
Command Mode
Global Configuration Mode
Example
Configure the spanning-tree mode as mstp:
TL-SG5428(config)# spanning-tree mode mstp
spanning-tree mst configuration
Description
The spanning-tree mst configuration command is used to access MST
Configuration Mode from Global Configuration Mode, as to configure the
VLAN-Instance mapping, region name and revision level. To return to the
