Turbo Schematic LEVO SL - Rear Cable Routing; Rear Brake Hose Routing

24
6.2. REAR CABLES
6.2.1. REAR BRAKE HOSE
REAR BRAKE
 Feed the rear brake hose into the non-drive side ICR cable port on the inside of the chainstay.
 Feed the cable though the nylon guide tubes and up the down tube.
 When the hose reaches the ICR port, gently guide it out of the non-drive side head tube cable port.
