Turbo Schematic LEVO SL - Pivot Bearings and Spacers Specifications

8
# PIVOT
SERVICE PART
NUMBER QTY MATERIAL Ø OD (mm) Ø ID (mm) WIDTH (mm) THREAD (mm) LENGTH (mm) TOOL
BEARING
NUMBER
A
Main pivot bearing
S210600003
2 Steel 24 12 6 N/A N/A N/A 6901-2RS
B
Horst link bearing
4
Steel 21 12 5 N/A N/A N/A 6801-2RS
C
Link at seat tube
2
D
Link at extension
2
E
Link at seatstay
2
H
Main pivot inner spacer
S210500019
2 Aluminum 19.5 12.1 3 N/A N/A N/A N/A
J
Link at seat tube inner spacer
2 Aluminum 19.5 12.1 3 N/A N/A N/A N/A
M
Link at seatstay spacers
4 Aluminum 19.5 12.1 3 N/A N/A N/A N/A
P
Horst link outer flip chip
2 Aluminum N/A N/A N/A N/A N/A N/A N/A
Q
Horst link outer spacer
4 Aluminum 21 12 2.5 N/A N/A N/A N/A
R
Horst link inner spacer
2 Aluminum 16 6 16 N/A N/A N/A N/A
S
Horst link inner flip chip
2 Aluminum N/A N/A N/A N/A N/A N/A N/A
4.2. PIVOT BEARINGS AND SPACERS — SPECIFICATIONS
